UNI-T AC/DC Modern Digital Auto Ranging Multimeter (Multitester True RMS)

Choose your country:

Buy at Amazon
  • Overview
  • FAQ
  • Reviews
Descriptions:
UT61 Series Digital Multimeters are products designed for multi-functional, high precision, high performance and automatic measurements.
1、Large LCD screen;
2、High resolution analog pointer display;
3、Full range overload protection;
4、Data hold, REL, Peak value measurement;
5、Low battery indication, backlight, and sleep mode;
6、External interface supports RS-232C and USB cable.
UT61 Series can measure AC/DC voltage and current (UT61D, UT61E has true RMS), resistance, diode, circuit continuity, capacitance, frequency, temperature, hFE, electromagnetic induction, etc.
UT61 Series complies with the standard IEC61010: CAT. III 1000V, CAT.IV 600V; they are widely used in Industrial Production and Service, Technological Research and Design, College Education (Laboratory, Courses), and Automotive Industry.

Features:
Display Count: 22000
Auto Range: √
True RMS: √
Bandwidth (Hz): 45Hz ~10kHz
Duty Cycle: 0.1% ~ 99.9%      √
Diode: √
Continuity Buzzer: √
Low Battery Indication:   ≤7.5V
Data Hold: √
Relative Mode: √
Peak Value: √
RS-232: √
LCD Backlight: √
Analogue Bar Graph: 46
Input Protection: √
Input Impedance for DCV: Around 10MΩ

Specifications:
Model: UT61E
DC Voltage (V): 220mV/2.2V/22V/220V/1000V ±(0.1%+2)
AC Voltage (V): 220mV/2.2V/22V/220V/750V ±(0.8%+10)
DC Current (A):    200μA/2200μA/22mA/220mA/2.2A/10A ± (0.5%+10)
AC Current (A): 200μA/2200μA/22mA/220mA/2.2A/10A ±(0.8%+10)
Resistance (Ω): 220Ω/2.2kΩ/22kΩ/220kΩ/2.2MΩ/22MΩ/220MΩ±(0.5%+10)
Capacitance (F): 22nF/220nF/2.2μF/22μF/220μF/2.2mF/22mF/220mF ±(3.0%+5)
Frequency (Hz): 10Hz-220MHz ±(0.01%+5)

General Characteristic:
Power: 9V Battery 6F22 (not included)
LCD Size: 65mm * 43 mm
Product Color: Red and Grey
Product Net Weight: 370g
Product Size: 180mm * 87mm * 47 mm
Packag Size: 22 * 16 * 6cm / 8.7 * 6.3 * 2.4in
Package Weight: 662g / 1.5lb

Package list:
1 * UNI-T UT61E Modern Digital Multimeters
2 * Test Lead
1 * Muli-Purpose Socket
1 * RS-232 Interface Cable
1 * PC Software CD
1 * English Manual
